USB Wall Charger - 65W - USB Type-C - GaN & PPS - White

USB ChargersSKU: CH-C65-1300-WH

Price:
Sale price$26.58 USD
Stock:
In stock

Description

Overview

This USB wall charger consists of a USB Type-C female on one end and a 1-15P plug on the other end. It is used to charge USB Type-C compatible smart phones, notebooks or tablets (such as MacBook, Chromebook, iPhone, iPad, Blackberry, Samsung, LG,HTC and Android devices). The USB-C port supports USB power delivery charging technology which is designed to charge Type-C notebooks and outputs a maximum of 65 watts.

The GaN (gallium nitride) technology offers the benefit being physically smaller and conducts higher voltages than traditional chargers. GaN chargers are more efficient in transferring current and conserving energy. Conserved energy enables a better flow to the charging device, resulting in faster charge times.

This charger is also incorporates PPS (programmable power supply) technology. It is compatible with PD3.0 and is also a significant update as PPS integrates two charging modes of high voltage & low current and low voltage & high current. PPS chargers have better compatibility and can support fast charging based on factors such as Qualcomm QC3.0/4.0 and HUAWEI super charge. PPS also reduces voltage adjustment in steps of 20mV, which is only one-tenth of the QC3.0 protocol, and allows a more precise adjustment of output voltage and current to shorten charging time and improve charging efficiency.

Compatible with smartphones, tablets & notebooks

This high performance charger allows charging for any smartphone, notebooks, or tablets (such as iPhone, iPad, Blackberry, Samsung, LG, HTC and Android devices). It delivers a maximum of 3A.

GaN and PPS

This charger contains the chemical compound Gallium Nitride which has greater power efficiency and are more efficient in transferring current and conserving energy. Conserved energy enables a better flow to the charging device, resulting in faster charge times. It is also a PPS (Programmable Power Supply) allows for a precise adjustment of output voltage and current to shorten charging time and improve charging efficiency.

Supports latest charging technology

This charger supports Power Delivery charging protocol, which is designed to provide simple, efficient battery charging at speeds faster than conventional USB chargers.

Specifications

Physical Characteristics
Color White
Molding Fire Retardant Material
Dimensions 56.2 x 50 x 28.7mm
Performance
Input 100V/240VAC 50/60Hz, 1.7A Max.
Output
5V/9V/12V/15V 3A, 20V/3.25A (PD)
3.3V-21V/3.25A (PPS)
Total Maximum Power 65 Watts
Supports Over Current Protection
Over Voltage Protection
Short Circuit Protection with Auto-Recovery
Over Temperature Protection with Auto-Recovery
Connector(s)
Connector A USB Type-C Female
Connector C 1-15P Male
Approvals
c(UL)us
Yes
FCC Yes
Environmental
RoHS Yes
Warranty Information
Warranty
1 YearĀ
Packaging Information
Package Quantity 1
Product Weight 0.23 lbs
