Description
This connector is extremely robust and offers a reliable locking system as speaker cable terminations. It features solid contacts with screw-type terminals including a stranded wire protection which also offers solder termination.
| Physical Characteristics | |
|---|---|
| Color | Blue |
| Connector Type | speakON |
| Temperature Range | -30℃ to +80℃ |
| Contact Plating | 4 µm Ag |
| Contacts | Brass |
| Insert | PBTP 20% GR |
| Locking Element | Zinc Diecast |
| Shell | PBTP 20% GR |
| Strain Relief | Polyacetal (POM) |
| Gender | Female |
| Electrical Characteristics | |
| Contact Resistance | ? 2 mΩ (after lifetime) |
| Dielectric Strength | 4 kVdc (peak) |
| Insulation Resistance | > 1 GΩ (after damp heat) |
| Rated Current Per Contact | 40 A rms continuous 50 A audio signal, duty cycle 50% |
| Rated Voltage | 250 V ac |
| Mechanical Characteristics | |
| Cable O.D. | 7 - 14.5 mm |
| Cable Retention | ≥ 220 N (subject to cable O.D. and material) |
| Lifetime | > 5000 mating cycles |
| Wire size | 4 mm² / 6 mm² (screw type terminals/soldering) 12 - 10 AWG |
| Wiring | Screw Type Terminals or Soldering |
| Locking Device | Quick Lock (Latch) |
| Environmental | |
| Flammability | UL 94 HB |
| Solderability | Complies with IEC 68-2-20 |
| Manufacturer Information | |
| Neutrik Part Number | NL4FX |
| Packaging Information | |
| Package Quantity | 1 |
| Product Weight | 0.02 lbs [0.01 kg] |
Spec Sheets
Product Weights
| SKU | Weight | |
| NT-NL4FXX-W-S | 0.02 lb |
