6 inch DisplayPort Male to DVI Dual-Link Female Adapter - Black

Video AdaptersSKU: AD-DP-DVI-DL

Price:
Sale price$31.59 USD
Stock:
In stock

Description

This adapter consists of a DisplayPort male on one end and a dual-link DVI female on the other. It is primarily used to connect a DisplayPort source such as PC/laptop to a DVI-D display such as; CRT, LCD monitors and projectors.

Application

Physical Characteristics
Length 6 inches
Color Black
Connector Plating Gold
Operating Temperature
0℃ to +45℃
Operating Humidity
10%to 85 % RH (no condensation)
Storage Temperature
-10℃ to +80℃
Storage Humidity
5%to 90 % RH (no condensation)
Connectors
Connector A DisplayPort Male + USB Male (power)
Connector B Dual-Link DVI-D Female
Performance
Dual-Link Resolution (Max) 2560 x 1600
Single-Link Resolution (Max)
1920 x 1080
Supports Deep Color 12bit
Supports 268.5/348.5 MHz Bandwidth
DP Version 1.1a
Frequency Range 50/60Hz
Power Requirement No external power needed
Power consumption (Max)
3W
Approvals
CE Yes
FCC Yes
Environmental
RoHS Yes
Reach Yes
Conflict Minerals Yes
Packaging Information
Packaging Quantity 1
Product Weight 0.10 lbs [0.05 kg]
SKU Weight
AD-DP-DVI-DL 0.11 lb
