This 8 port HDMI video extender allows you to extend a maximum of eight 3D/HD displays up to 131ft (40 meters) away from your source device over Cat6 cables at a resolution of 4Kx2K@30Hz. It also has a single HDMI output for a local monitor.
*Please note that the transmitter must be placed in a well ventilated area to avoid overheating.
|
Physical Characteristics
|
| Color
|
Black
|
| Housing
|
Metal Enclosure
|
| Dimensions |
Transmitter: 295 x 82 x 18mm (W x D x H)
Receiver: 79.5 x 69 x 16.5mm (W x D x H) |
| Operating Temperature
|
0C to +40C (+32F to +104F)
|
| Storage Temperature |
-20C to +60C (+-4F to +140F) |
| Relative Humidity |
20~90% RH (non-condensing) |
|
Power
|
| Power Supply |
12V/2.5A DC Power (US/EU Standards, CE/FCC/RoHS Certified)
|
| Power Consumption |
19.2W |
|
Connector(s)
|
| Transmitter x 1
|
1 - HDMI Female Input
1 - HDMI Female Output
8 -RJ45 Female Output
1 - IR Output
1 - EDID Dip Switch
1 - Micro USB Update Port |
Receiver x 8
|
1 - HDMI Female Output
1 - RJ45 Female Input
1 - IR Input |
|
Performance
|
| Video Bandwidth |
297MHz/10.2Gbps |
| Video Resolution |
480i ~1080p50/60Hz, 4Kx2K@30Hz (4:4:4) |
| Color Depth |
8-bit, 10-bit, 12-bit (1080p@60Hz); 8-bit (4K@30Hz) |
| Color Space |
RGB, YCbCr 4:4:4/4:2:2. YUV 4:2:0 |
| Audio Formats |
LCPM 7.1CH, Dolby True HD and DTS-HD Master Audio |
| Transmission Distance |
1080p@60Hz - 70m
4K@30Hz - 40m |
| HDMI Compliance |
HDMI 1.4 |
| HDCP Compliance |
HDCP 1.4 |
| Supports |
Advanced EDID management
12V POC function (only from transmitter to receiver) |
|
Approvals
|
| Power Adapter
|
c(UL)us
|
|
Environmental
|
| RoHS
|
Yes
|
| CE |
Compliant |
| FCC |
Compliant |
|
Packaging Information
|
| Package Quantity
|
1
|
| Product Weight
|
5.07 lbs [2.30kg] |
|
Contents
|
| Included in Package
|
1 - HDMI 1x8 Splitter
8 - Receivers
1 - IR Blaster
8 - IR Receiver
2 - Mounting Ears
1 - 12V/2.5A DC Locking Power Adapter
8 - Machine Screws (KM3*4)
1 - User Manual
|
