This 1x8 DVI splitter enables you to display one DVI source to eight DVI displays simultaneously. It is typically used to connect DVI sources such as DVD players, Blu-ray players, satellite receivers or gaming systems to DVI displays such as HDTVs, HD projectors or DVI monitors.
Features
- 1x DVI input and 2xDVI output/ 4xDVI output/ 8xDVI output
- Support resolution up to 4096x2160@30Hz
- Support for long distance signal transmission
- Installs in minutes, No loss of quality
- Supports wide range voltage DC input (DC5V)
|
Physical Characteristics
|
| Color |
Black |
| Housing |
Metal Enclosure |
| Operating Temperature |
-5 to +45? |
| Storage Temperature |
-15 to +55? |
| Operating Humidity |
10 to 90%RH (No Condensation) |
| Storage Humidity |
5 to 95%RH (No Condensation) |
|
Connectors
|
| Video Input Connector |
1 - DVI-D 29-pin Female |
| Video Output Connector |
8 - DVI-D 29-pin Female |
|
Power
|
| Max. working current |
1.2A/5V |
| Power Supply |
AC 100V?240V 50HZ/60Hz, DC5V/2A/12V |
|
Performance
|
| DVI Resolution |
4096x2160@30Hz |
| Max. Signal Bandwidth |
340MHz |
| Max. Baud Rate |
3.4Gbps Serial Link |
| Cable Distance |
10 m (Max.) |
| Input/Output TMDS signal |
0.5~1.5Volts p-p(TTL) |
| Input/Output DDC signal |
5Volts p-p (TTL) |
|
|
|
Approvals
|
| Power Cable |
c(UL)us |
|
Packaging Information
|
| Package Quantity |
1 |
| Dimensions |
440x130x44 (LxWxH) mm |
| Product Weight |
5.6 lbs [2.5kg] |
| Package Weight |
6.6 lbs [3kg] |
|
Contents
|
| Included in Package |
1 - DVI Splitter |
|
1 - Power Adapter |
|
1 - User Manual |
