Overview
This 5MP PTZ indoor IP based dome camera provides sharp, high definition images in daylight or nighttime settings. The camera has a focal length of 2.7 mm to 13.5mm lens with 5x optical zoom which delivers 106.9 ° to 30.6 ° horizontal field of view. Its maximum resolution is 2880 x 1620 at 30 fps and supports Ultra 265 video compression technology, which assures savings in bandwidth and storage. The camera is IP based with integrated PoE technology which makes for a quick and easy installation over a single CAT5e/CAT6 cable. It has 98 feet of IR range using an IR cut filter and IR LEDs.
 |
Features
|
Application
The typical application for most security cameras networks is to connect the IP cameras to a NVR/DVR for simplified playback and additional storage space. Alternatively you can use an IP cameras as a standalone camera and not part of a network by connecting it directly to a POE switch and save the recording on a micro SD card.
NVR Setup
Standalone Camera Setup
Specifications
| Camera | |
|---|---|
| Image Sensor | 1/2.7" (5 MP) progressive scan CMOS |
| Minimum Illumination | Color: 0.003 lux @ (F1.2, AGC on) 0 Lux with IR |
| Day/Night | IR-cut filter with auto switch (ICR) |
| Shutter | Auto/Manual, 1 ~ 1/100000s |
| S/N | >56dB |
| WDR | 120dB |
| Lens | |
| Lens Type | 2.7~13.5mm@F1.2, AF automatic focusing and motorized zoom lens |
| Iris | Auto aperture |
| Angle of View (H) | 106.9°~30.6° |
| Angle of View (V) | 56.0°~17.7° |
| Angle of View (O) | 131.5°~39.8° |
| DORI | |
| DORI Distance | 2.7mm Lens, 70.9m(232.5ft) Detect, 28.4m(93.0ft) Observe, 14.2m(46.5ft) Recognize, 7.1m(23.3ft) Identify 13.5mm Lens, 247.5m(812.0ft) Detect, 99.0m(324.8ft) Observe, 49.5m(162.4ft) Recognize, 24.8m(81.2ft) Identify |
| Illuminator | |
| IR Range | Up to 30m (98ft) IR Range |
| Wavelength | 850nm |
| IR On/Off Control | Auto/Manual |
| Video | |
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| Frame Rate | Main Stream: 5MP (2880*1620),Max 30fps; Sub Stream: 720P (1280*720), Max 30fps; Third Stream: D1 (720*576), Max 30fps |
| Video Bit Rate | 128 Kbps~16 Mbps |
| U-code | Supported |
| OSD | Up to 8 OSDs |
| Privacy Mask | 24 areas, up to 4 areas per scene |
| ROI | Supported |
| Video Stream | Triple streams |
| Image | |
| White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
| Digital Noise Reduction | 2D/3D DNR |
| Smart IR | Supported |
| Flip | Normal/Flip Vertical/Flip Horizontal/180° |
| HLC | Supported |
| BLC | Supported |
| Defog | Digital Defog |
| Intelligent | |
| Smart Intrusion Prevention | Support false alarm filtering: Line crossing detection, Intrusion detection, Enter Area detection, Leave Area detection |
| Face Capture | Support |
| Events | |
| Basic Detection | Motion detection, Tampering alarm, Audio Detection |
| General Function | Watermark, IP Address Filtering, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication |
| Audio | |
| Audio Compression | G.711U, G.711A |
| Audio Bitrate | 64 Kbps |
| Two-Way Audio | Supported |
| Suppression | Supported |
| Sampling Rate | 8KHz |
| Storage | |
| Edge Storage | Micro SD, up to 256GB |
| Network Storage | ANR, NAS(NFS) |
| Network | |
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP, SSL/TLS |
| Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API, SDK |
| User/Host | Up to 32 users. 2 user levels: administrator and common user |
| Security | Password protection, strong password, HTTPS encryption, basic and digest authentication for RTSP, digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF |
| Client | EZStation EZView EZLive |
| Web Browser | Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below |
| Pan & Tilt | |
| Pan Range | 350° (endless) |
| Pan Speed | 0.1°/s ~ 200°/s Preset speed: 60°/s |
| Tilt Range | 0° ~ 90° |
| Tilt Speed | 0.1° ~ 50°/s Preset speed: 50°/s |
| Number of Presets | 1024 |
| Preset Patrol | 16 patrols, up to 64 presets for each patrol |
| Patrol Stay Time | 15s~1800s |
| Preset Image Freeze | N/A |
| Home Position | Supported |
| Interface | |
| Audio I/O | N/A |
| Alarm I/O | 1/1 |
| Serial Port | 1 RS485 |
| Built-In Mic | Supported |
| Built-In Speaker | Supported |
| WIFI |
Support (IEEE802.11b/g/n) |
| Network | 1 * RJ45 10M/100M Base-TX Ethernet |
| Video Output | N/A |
| Certification | |
| EMC | FCC Part 15 EN 55032:2015 EN 55024:2010 EN 61000-3-2:2014 EN 61000-3-3-2013 |
| Safety | IEC 62368-1 EN 62368-1 UL 60950-1 |
| Environment | CE-ROHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); REACH (Regulation (EC) No 1907/2006) |
| NDAA Compliant | Yes |
| General | |
| Power | DC12V(±25%), PoE (IEEE 802.3af, Mode B – Pins 4, 5, 7 and 8) Power consumption: MAX 15W |
| Power Interface | Ø 5.5mm coaxial power plug |
| Dimensions (Ø x H) |
Φ129 x 143.6mm (Φ5.1€™€™ x 5.7€™€™) |
| Weight | 0.76kg(1.67lb) |
| Working Environment/Storage Environment | -10„ƒ~50„ƒ(14°F ~ 122°F)，Humidity: ‰¤95% RH (non-condensing) -40„ƒ~70„ƒ(-40°F ~ 158°F)，Humidity: ‰¤95% RH (non-condensing) |
| Surge Protection | 4KV |
| Reset Button | Supported |
| Protection | Ingression protection: N/A Vandal resistant: N/A |
Phantom Camview iOS App
Supports iOS 8.0 or later & requires macOS 11.0 or later and a Mac with the Apple M1 chip or later. Compatible with iPhone, iPad, iPod touch and Mac.
3-YEAR WARRANTY
Infinite Cables Inc. offers a 3-year warranty on all cameras and hard drives to be free from defects in material and workmanship.
This warranty is available to the original purchaser with proof of purchase. This warranty does not apply to any damage or product failure that is caused beyond Infinite Cables’ control, including but not limited to, misuse, neglect, accidental damage, improper installation or application, alteration, acts of God, or normal wear and tear. Infinite Cables is not responsible for any costs of removal or installation. Infinite Cables’ sole and exclusive obligation under this warranty shall be limited to repair or replacement of the defective item at our discretion.
Infinite Cables makes no other warranties expressed or implied including without limitation and warranty of fitness for a particular purpose. Infinite Cables will not be liable for damages of any kind including lost or anticipated profits, delay, consequential or special damages.
| SKU | Weight | |
| SC-6252W-5X-PTZ | 1.3 lb |
