This singlemode fiber optic media converter can extend a 10/100 Mbps Ethernet connection up to 30 km over a singlemode SC fiber optic cable. The converter can be used as a standalone unit or in pairs. It can also be mounted into a 19" media converter chassis.
| Physical Characteristics |
|---|
| Color |
Black |
| Dimensions |
94mm x 72mm x 25mm (L x W x H) |
| Housing |
Metal |
| Operating Temperature |
0℃ ~ 50℃ |
| Relative Humidity |
5% to 8% (non-condensation) |
| Standards |
IEEE802.3, IEEE802.3U, 10/100Base-TX, 10/100Base-FX |
| Power |
|---|
| Power Supply |
1A@+5VDC or 110-260VAC or 48VDC
|
| Power Consumption |
2.5W |
| Connectors |
|---|
| Fiber Connector |
SC |
| Ethernet Connector |
RJ45 UTP |
| Performance |
|---|
| Media Supported |
Singlemode Fiber (8.3/125um, 9/125um, 10/125um) |
| Referenced Transmission Distance |
Dual-Fiber Singlemode: 30km |
| Data Forward Rate |
10Mbps: 14,880pps100Mbps: 148,800pps
|
| Features |
High-Performance Kernel, Broadcast Storm Control, Flow Control, CRC Error Checking |
| LED |
FX Link/Act (Connection status display for fiber link)TX Link/Act (Connection status display for electric link)PWR (power is on)FDX (transceiver works in full duplex mode)FX (fiber signal is detected)TX (transfer rate of UTP interface is 100Mbps
|
| Certifications |
|---|
| CE |
Compliant |
| FCC |
Compliant |
| RoHS |
Compliant |
| Packaging Information |
|---|
| Package Quantity |
1 |
| Product Weight |
0.85 lbs [0.03kg] |
| Warranty Information |
|---|
| Warranty |
1 Year |
